Description
Product introduction
This product adopts a unique and precise design in machinery, optics and light source, which makes the indentation imaging clearer and the measurement more accurate. It adopts a new color touch screen LCD display, and the operation interface adopts a menu structure, which can be selected on the operation panel and can be converted between various hardness values. This machine is equipped with a 10 times digital display measuring microscope and a 40 times objective lens to participate in the measurement, so that the measurement and application range are wider, and the large screen is used, the operation is more intuitive and clear, and the test method and test force can be displayed on the screen, and also the indentation length, hardness value, test force retention time, measurement times, date, time, hardness conversion value and other functions. It has functions such as scale conversion, storage, printing and RS232 interface. The indenter and the objective lens can automatically switch positioning accuracy, which is more efficient. It has a threaded interface for connecting a digital camera and a CCD camera. It is convenient to choose a computer and hardness analysis and measurement software.
1.The machine has the functions of data storage, query and average value calculation.
2.The machine adopts three-point positioning, which is more accurate and repeatable.
3.The supporting shrapnel of the machine is made of imported special customized material, which has high toughness, high fatigue resistance and is not easy to deform
4.The operation interface of the machine adopts the humanized format, the number area and function column type. The menu function classification is clear and detailed, and the lighting brightness, menu selection and objective selection all have memory function.
5 .The 10X and 40X objective lenses in high-end models have both measurement and observation functions
6.The hardness conversion table is classified and refined, which is a perfect conversion table in the industry at present.
7.The light source system adopts self-developed new LED lighting, with long service life and low calorific value.
Technical Specifications
| Model | MHV-1000BZ |
| Test force | 10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、 200gf (1.96N)、300gf (2.94N)、500gf(4.9N)、1kgf (9.8N) |
| Minimum test unit | 0.25µm |
| Conversion ruler | HRA、HRB、HRC、HRD、HRF、HV、HK、HBW、HR15N、HR30N、HR45N、HR15T、HR30T、HR45T |
| Hardness test range | 5~3000HV |
| Test force application method | Automatic (loading, holding, unloading) |
| Test microscope magnification | 100X(Observed)400X(test) |
| Test force holding time | 1~60s |
| X-Y Test Table | Size:100*100mm
Maximum movement:25*25mm |
| Data output | LCD display readout, built-in printer and RS-232 interface |
| Maximum height of specimen | 90mm |
| Distance from center of indenter to outer wall | 95mm |
| power supply | AC220V+5%,50-60Hz |
| Size | 405*290*480mm |
| Weight | 40Kg |
Appendix
| Name | Qty | Name | Qty |
| Weight shaft | 1 | Weight | 6 |
| Cross test table | 1 | Sheet holding table | 1 |
| Flat clamping table | 1 | Filament clamping table | 1 |
| Screwdriver | 2 | Adjusting screw | 4 |
| Small spirit level | 1 | 10X test eyepiece | 1 |
| Micro Vickers hardness block (high block, low block) | One of each | Spare fuse (2A) | 2 |
| power cable | 1 | Product certification | 1 |
| Instruction Manual | 1 |
